Supply Longer Life Medical Devices
4 Years
| Ask Lasest Price | |
| Brand Name : | Longermay |
| Model Number : | LGM610 |
| Supply Ability : | 1000 Set/Sets per Month |
| Price : | $200.00 - $350.00/Sets |
Model | BYZ-810& BYZ-810D | |||||
Infusion Rate | 50/60ml Syringe: 0.1ml/h~1500ml/h(0.1ml/h step) 30ml Syringe: 0.1ml/h---900ml/h(0.1ml/h step) 20ml Syringe:0.1ml/h---600ml/h(0.1ml/h step) 10ml Syringe 0.1ml/h---300ml/h(0.1ml/h step) | |||||
Rate Accuracy | Within±3%(after correct calibration) | |||||
Maximum Stackable | 8pcs | |||||
Mechanical Accuracy | Within±2% | |||||
Bolus Rate | 50(60)ml Syringe:1200ml/h 30ml Syringe:720ml/h 20ml Syringe:480ml/h 10ml Syringe:240ml/h | |||||
Volume Limit | 0.1ml---9999.9ml(0.1ml step) | |||||
Total Injection | 0.1ml---9999.9ml(0.1ml step) | |||||
Maximum Infusion Pressure | 150kPa | |||||
Occlusion | High 800mmHg±200mmHg(106.7kPa±26.7kPa) Medium 500mmHg±100mmHg(66.7kPa±13.3kPa) Low 300mmHg±100mmHg(40.7kPa±13.3kPa) | |||||
Audible and Visible Alarms | Occlusion、Equipment failure、Software Exception、Injection
finish、Limited finished、Battery running out、Improperly installed 、Abnormal operation ect. | |||||
Power Source | 100-240Vac,50/60Hz;Internal rechargeable Li
battery,capacity³1800mAh,voltage=11.1V,4 hours backup time at the
rate of 25ml/h(appointed medium rate in IEC60601-2-24)for the new battery charged for 12 hours.To facilitate the use in some special occasions,the machine's DC outlet can be an external DC 12V 2A standby power supply. | |||||
KVO Speed | 0.1~5m/h(0.1ml/h step) | |||||
Power Consumption | 35VA | |||||
Fuse | T2AH/250V,2pcs installed | |||||
IP Classification | IPX2 | |||||
Equipment Classification | Class I,intermal power supply,Type CF | |||||
Operation Environment | a)Ambient temperature: +5℃~+40℃ b)Relative Humidity:20%~90% c)Atmospheric pressure:86.0kPa~106.0kPa | |||||
Transport&Storage Condition | a)Ambient temperature: -20℃~+55℃ b)Relative Humidity:≤95% c)Atmospheric pressure:50.0kPa~106.0kPa | |||||
Syringe | Compatible with 10ml,20ml,30ml,50/60ml syringe of any brands after
correct calibration | |||||
Dimension | 280mm(L)×210mm(W)×130mm(H) | |||||
Net Weight | 2.2kg | |||||
Package Reference | 1pc Carton:3.2KG,36cm(L)×29cm(W)×18cm(H) 2pcs Carton:7.2KG,39cm(L)×38cm(W)×31cm(H) 3pcs Carton:10.7KG,58cm(L)×38cm(W)×31cm(H) | |||||
|
