Supply Longer Life Medical Devices
4 Years
| Ask Lasest Price | |
| Brand Name : | Logermay |
| Model Number : | LGM-1070 |
| Supply Ability : | 1000 Set/Sets per Month |
| Price : | $950.00 - $1,200.00/Sets |
Microscope | ||
Microscope Type | Galileo magnification changer with converging | |
Magnification Change | Switch zoom | |
Eyepiece | 10x | |
Magnifications (Field of View) | 10x( φ22.5 mm ), 16x( φ14 mm ) | |
Pupilary Adjustment | 55 mm~82 mm | |
Diopter Adjustment | ±6D | |
Slit Illumination | ||
Slit Width | continuously variable from 0 ~14 mm adjustable(at 14 mm, slit
becomes a circle ) | |
Slit Height | continuously variable from 1 mm~14 mm | |
Slit Angle | 0°~180° ( continuously adjustable both vertical and horizontal) | |
Slit Inclination | None | |
Aperture Diameter | φ14mm, φ9mm, φ5.5mm, φ0.3mm | |
Lamp | 6V/20W Halogen bulb | |
Maximum Illuminance | ≥150,000 Lx | |
Filter | Thermal safety, red-free, cobalt blue | |
Power | ||
Input Voltage | AC 220V /110V ±10% | |
Electrical Safety Standard | IEC 60601-1, Class I, Type B | |
Dimension & Weight & Accessories | ||
Packing Volume | 720 mm x 495 mm x 480 mm | |
Total Weight | 23 Kg | |
Optional Accessories | Applanation tonometer, trihedron lens, gonioscope, funduscope,
aspheric lens | |
|
