Supply Longer Life Medical Devices
4 Years
| Ask Lasest Price | |
| Brand Name : | Longermay |
| Model Number : | LGM-620 |
| Supply Ability : | 1000 Set/Sets per Month |
| Price : | $260.00 - $450.00/Sets |
Item | Technical Parameter |
IV Sets | Standard single use IV sets(20 and 60d/ml, with diameter 3.4~4.5mm) |
Flow Rate Range | 1.0ml/h with 0.1ml/h; 100-1200ml/h with 1ml/h |
Flow Rate Increment | 1.0-100ml/h with 0.1ml/h; 100-1200ml/h with 1ml/h |
Flow Rate Deviation | <±5%(after calibration) |
VTBI | 0.1~9999ml |
Infused Volume | 0~999ml |
Time Setting | 1 min to 99h59min |
Purge Rate | 600ml/h, displaying purge volume |
KVO | 1ml/h~5ml/h, adjustable |
Keypad | Numeric Keypad, user friendly |
BOLUS Mode | Available for Bolus mode, flow rate adjustable |
Night Mode | Night mode, No operation for 5mins, LCD brightness lower
automatically |
Occlusion Pressure Detection | Occlusion Pressure Sensor, detection range: 40-140Kpa, 10 levels
adjustable, auto pressure release function |
Air-in-line Detection | Air bubble detected by ultrasonic with 10 setting, 50~300μL |
Alarm &Volume | 10 settings |
Anti-reverse Function | Anti-reverse function on motor to prevent upstream |
IV Set Management | Open System, Can accept all kinds of IV Set after calibration |
Self-Testing | Self-Testing when start up and during infusing |
Audio and Visual Alarms | Air-in-line, Door open, occlusion, parameter, IV Ste not
calibrated, infusion finished, No operation, Leakage, battery low,
Pump error. Motor reverse, AC power lost, etc. |
Display | 3.5” Brightness LCD |
AC power | AC:100V~240V, 50Hz/60Hz,≤25VA |
Battery | Rechargeable Lithium battery: DC11.1V, 3000mAh, life:≥10 hours
remaining battery displayed |
Operation | Temperature: 5℃~40℃, Relative humidity:20%~90%, Atmospheric
pressure:70~106Kpa |
Transportation and Storage | Temperature: 20℃~55℃, Relative humidity:10%~90%, Atmospheric
pressure:70~106Kpa |
Classification | Class I, CF, IP*3 |
Dimension | 150mm*10mm*210mm |
Weight | 1.7KG |
|
