Supply Longer Life Medical Devices
4 Years
| Ask Lasest Price | |
| Brand Name : | Logermay |
| Model Number : | LGM-1018 |
| Supply Ability : | 1000 Set/Sets per Month |
| Price : | $20,000.00 - $26,500.00/Sets |
Item | Content | Technical Parameter | ||||
Power Supply | Voltage | 380V | ||||
Frequency | 50Hz | |||||
Capacity | ≥50kVA | |||||
internal resistor | ≤0.23Ω | |||||
High voltage Generator | Power Output | 50KW | ||||
Inverter Frequency | 60 KHz | |||||
Tube Voltage | 40kV—150kV | |||||
Tube Current | 10mA—630mA | |||||
Exposure time | 1ms—10000ms | |||||
mAs range | 0.4mAs—1000mAs | |||||
Digital Controlled X-ray Tube | Large Focus/Small Focus | 1.2mm /0.6mm | ||||
Input Power | Big focus 50kW / Small Focus 20kW | |||||
thermal capacity | 240kHU（161kJ） | |||||
Anode target surface inclination | 12° | |||||
Rotary anode speed | 2700rpm-50Hz，3200rpm-60Hz | |||||
thermal capacity of x-ray tube assembly | 900KJ | |||||
continuous heat dissipation power of tube assembly(without fan) | 180W | |||||
Collimator | Inherent filtration | 1.0mm AI | ||||
Light Source | LED | |||||
Radiography Table | Table size(L×W) | 2000cm×710cm | ||||
Grid Size | 17×17inch | |||||
Table longitudinal movement | ≥130cm | |||||
Table transverse movement | ≥20cm | |||||
Cassette longitudinal Movement Distance | 108cm | |||||
Tube assembly up-down movement | 1000mm | |||||
Bucky Stand | Vertical moving range | ≥1200mm | ||||
Bucky size | 17×17inch | |||||
Ratio | 10：1 | |||||
Wire Flat Panel Detector | Vision size | 434mm×434 mm | ||||
Pixel gap： | 154 μm | |||||
Imaging time | less than 2~6s | |||||
Limiting resolution | 3.3 linepair/mm | |||||
A / D conversion： | 16 bit | |||||
Computer | CPU System | 2.9GHz | ||||
Memory | 8GB | |||||
Disk Capacity | 1000GB | |||||
Size of LCD Screen | 24 inch | |||||
Case 1 | 244cm×113cm×102cm，2.81m³ | |||||
G.W. 650KG N.W.650KG | ||||||
Case 2 | 208cm×65cm×43cm，0.58m³ | |||||
G.W. 200KG N.W.180KG | ||||||
|
